N-Type Module
Model: HP580W-NS
Dimension: 2278*1134*30 mm
Single glass TOPCON solar panel
power range: 580 W
The new N-type solar panel efficiency ensures maximum power generation, and now the price of solar panels is competitive.
New technologies such as SMBB technology, lossless cutting technology, and weak light technology are applied to solar panels,
Not only is the return on investment high, but the initial investment cost is also reduced by more than 50%.
ELECTRICAL DATA(STC) |
|||||
MODEL |
HP570W-NS |
HP575W-NS |
HP580W-NS |
HP585W-NS |
HP590W-NS |
Peak Power Watts-PMA×(Wp)* |
570 |
575 |
580 |
585 |
590 |
Power Output Tolerance-PMAX(W) |
0~+5 |
||||
MECHANICAL DATA |
2278*1134*30mm / 28kg |
||||
Maximum Power Voltage-VMPP(V) |
42.99 |
43.17 |
43.35 |
43.53 |
43.71 |
Maximum Power Current-IMPP(A) |
13.26 |
13.32 |
13.38 |
13.44 |
13.50 |
Open Circuit Voltage-Voc(V) |
51.99 |
52.15 |
52.31 |
52.47 |
52.63 |
Short Circuit Current-ksc(A) |
13.89 |
13.95 |
14.01 |
14.07 |
14.13 |
Module Efficiency(%) |
22.1 |
22.3 |
22.5 |
22.6 |
22.8 |
Solar Cell
Solar cells serve as the backbone of our solar panels, featuring Tier 1 brands such as Longi, TW Solar,
and Jinko Solar, Trina Solar cell ,
With no color variation, these cells boast high efficiency and incorporate cutting-edge technology.
Prior to panel production, each individual solar cell undergoes meticulous inspection and sorting.
Production Equipment
Unmatched Consistency, Unrivaled Efficiency:
Achieve unmatched consistency and unrivaled efficiency with our production equipment,
showcasing the third-generation line tailored for Half Cut Solar Cells such as the 166, 182, and 210 cell variants.
The combination of high automation and intelligence ensures a flawless production process.
Auxiliary materials and accessories
Dependable Quality Throughout:
Depend on the consistent quality of your solar panels by choosing components with high-quality auxiliary materials. Our adherence to a standard production process guarantees traceability,
and the double assurance of machine detection and manual checks ensures dependability in every component.
