PERC Solar Cell Technology
Model: HP360/370/380W-PS
Dimension: 1755*1038*30/35 mm
Single Glass solar panel
Power range: 360W-380 W
Module efficiency up to 21.5 %
Small size panel for residential roof
solar panel installation easy
Lower LCOE & system cost
Model | HP360W-PS | HP365W-PS | HP370W-PS | HP375W-PS | HP380W-PS |
Basic Parameters | 1755*1038*30/35mm weight : 20kg | ||||
Rated Maximum Power at STC | 360W | 365W | 370W | 375W | 380W |
Maximum Power Voltage(Vmp/V) | 33.9 | 34.1 | 34.3 | 34.5 | 34.7 |
Maximum Power Current(Imp/A) | 10.62 | 10.71 | 10.79 | 10.88 | 10.96 |
Open Circuit Voltage(Voc/V) | 40.5 | 40.7 | 40.9 | 41.1 | 41.3 |
Short Circuit Current(Isc/A) | 11.35 | 11.42 | 11.49 | 11.56 | 11.63 |
Module Efficiency(%) | 19.8% | 20.0% | 20.3% | 20.6% | 20.9% |
STC: Irradiance 1000w/m², Cell Temperature 25℃, AM 1.5G |
Solar Cell
Solar cell is the most important basic part of photovoltaic components,
Because we use the mature solar cells from tire 1 companies such as Longi, TW Solar
It has the advantages of high efficiency, good quality, standardization and so on
Mono and MBB solar cells technical are the mainstream
Production Equipment
The third -generation production line of the factory is suitable for Half Cut Solar Cell, such as 166 182 and 210 cell
Highly automated, intelligent, mechanized
Reduce the error of artificially, the consistency of each solar Panel is guaranteed
The frame and the silicone are done by the machine
Very high efficiency and great production capacity
Auxiliary materials and accessories
Solar panel components apply high -quality auxiliary materials,
Standard production process
The whole process can be traced
Double guarantees for machine detection and manual detection
